Digital Tube Microm. Sph. Anvil/Spindle

Full Description: This Digimatic Tube Micrometer allows you to measure curved surfaces such as the wall thickness of tubes, bearings and rings.; Magnetic stand size (LXWXH): 32; Base size (LxWxH): 12.6; Mass [g]: 470; Range [mm]: 50 – 75; Battery life: Approx. 2,4 years; Functions: Model with spherical anvil and spindle; Inch-Metric: Metric; Delivered: Including box,?setting standard?(from 25 mm upward), key, 1 battery; Digital/Analog: Digital; Max. Permissible Error J MPE: ?2 ?m; Accuracy [?m]: ?2; Measuring spindle: With spindle lock, ?6,35 mm, spindle pitch 0,5 mm; Measuring face: Carbide-tipped, micro-lap finish; Scale: Thimble and sleeve satin chrome finish, ?18 mm; Anvil / Spindle: Type B, spherical anvil and spindle SR=4 mm; Digital step: 0,001 mm;Product Link: https://shop.mitutoyo.eu/web/mitutoyo/en/mitutoyo/01.02.01.071/Digital%20Tube%20Microm.%20Sph.%20Anvil/Spindle/$catalogue/mitutoyoData/PR/395-273-30/index.xhtml
