Digital Indicator ID-C

Full Description: This is a multifunction standard indicator that is reliable and easy to use.

Bidirectional communication e.g. to perform parameter setting from a PC (Digimatic S 1 interface) is possible.
The ABSOLUTE sensor means you don?t have to carry out origin setting every time you power it on, saving you time and hassle.
Excellent visibility with a large digital/analog display.
Model with 0,5 ?m digital step is available.
Measurements such as simple calculation and peak detection are possible.
Equipped with a calibration schedule warning function.
GO/?NG judgement is performed by setting the upper and lower tolerances.
Display 330? rotatable.
A function lock protects the display against unauthorised use.
; Mass [g]: 170; Range [mm]: 12.7; Power supply report: 1 battery CR2032; Battery life: Approx. 2700 hours (continuous use); Type: EN ISO Standard; Inch-Metric: Metric; Delivered: Including CR2032 battery, battery lid opener, weight, certificate of inspection; Contact point: Carbide ball, thread: M2.5×0.45; Digital/Analog: Digital; H MPE (Hysteresis): 0.002 mm; R MPE (Repeatability): 0.002 mm; Stem ?: 8 mm; Max. Permissible Error E MPE: 0.003 mm; Digital step: 0.0005 mm/0.001 mm/0,01mm; Display: LCD, character height 11 mm, 330? rotatable; Low voltage alarm: Low voltage, setting errors, sensor error, display overflow a.s.o.; Max. response speed [mm/s]: Unlimited; Protection: IP42; Digimatic data output: Yes; Inch/Metric switchable: No; Max. Permissible Error E MPE (Total Range): 0.003 mm; Measuring force MPL: 0.4-0.7 N; Measurement frequency (MAX/MIN/RANGE): 50 times/s; Digital Scale: Electrostatic capacitance type absolute linear encoder; Analog bar resolution switchable: Yes; Digital step switchable: Yes; Digimatic S1 Bidirectional interface: Yes;Product Link: https://shop.mitutoyo.eu/web/mitutoyo/en/mitutoyo/1300442458734/Digital%20Indicator%20ID-C/$catalogue/mitutoyoData/PR/543-705/index.xhtml
